SAGAR TMT (thermo-mechanically-treated) rebars (reinforcing bar) are essential tension devices used in reinforced concrete and masonry structures to enhance concrete strength under tension. Our stringent physical and mechanical specifications significantly elevate the tensile strength of structures. The hot rolled round bars with surface deformations ensure robust bonding with concrete.
SAGAR TMT undergoes an integrated manufacturing process starting from ironmaking. Premium-grade iron ore and pellets are processed into high-quality sponge iron at our facilities, subsequently transformed into crude steel in our steel melting shop.
Our flagship offering, Fe-415, Fe-500 & Fe-500D stands out among available options and sizes. Through meticulous control over manufacturing parameters, rigorous lab testing, and stringent quality control measures, we consistently deliver top-quality TMT rebars. The superior product quality reduces steel usage in construction, leading to cost savings, thus positioning SAGAR TMT as an economically viable choice.
We're thrilled to introduce our newest offering: DWARKA TMT. Crafted with state-of-the-art technology, DWARKA TMT is designed to not only meet but exceed all your construction requirements. Our commitment to innovation and quality ensures that every bar is engineered to deliver superior performance, strength, and durability. Whether you're building a residential complex or a commercial structure, Dwarka TMT is your trusted partner in achieving excellence and reliability in every project.
Why DWARKA TMT Rebars:-
1. Exceptional Corrosion Resistance
2. Consistent Quality Assurance Measures
3. Enhanced Flexural Strength
4. Environmentally Friendly Production Methods
5. Optimal Weldability Characteristics
Premium quality TMT bars engineered for superior performance and durability in construction
8 , 10 , 12 , 16 , 20 , 25 , 28 & 32 mm TMT.
Fe-415 , Fe-500 , Fe-500D
| Physical / Mechanical Properties | Unit | IS: 1786 Fe 415 | IS: 1786 Fe 500 | Sagar TMT |
|---|---|---|---|---|
| Yield Stress | N/mm² | 415 min | 500 min | 450-550 |
| Tensile Strength | N/mm² | 485 min (10% over YS) | 545 min | 520-680 |
| Elongation | % min | 14.5 min | 12% min | 18-22% |
| Section | Wt. (kg./Mtr) | Tolerance Limit (in kg/m) | Sagar Shakti TMT Avg. Wt. | Variation in % |
|---|---|---|---|---|
| 8 mm | 0.395 | 0.367 - 0.423 | 0.375 | ±7 |
| 10 mm | 0.617 | 0.574 - 0.660 | 0.580 | ±7 |
| 12 mm | 0.888 | 0.844 - 0.932 | 0.850 | ±5 |
| 16 mm | 1.580 | 1.501 - 1.659 | 1.510 | ±5 |
| 20 mm | 2.470 | 2.396 - 2.544 | 2.410 | ±3 |
| 25 mm | 3.850 | 3.735 - 3.965 | 3.750 | ±3 |
| 28 mm | 4.830 | 4.685 - 4.975 | 4.730 | ±3 |
| 32 mm | 6.310 | 6.120 - 6.500 | 6.210 | ±3 |
| Size (mm) | No. of TMT in a Bundle | Weight per Meter (in Gram) | Weight of Bundle in Kg. | % Variation in Weight |
|---|---|---|---|---|
| 8 | 20 | 375 | 90 | ± 2 |
| 10 | 15 | 580 | 103 | ± 2 |
| 12 | 10 | 850 | 101 | ± 2 |
| 16 | 5 | 1510 | 92 | ± 2 |
| 20 | 2 | 2410 | 59 | ± 2 |
| 25 | 1 | 3750 | 45.5 | ± 2 |
| 28 | 1 | 4730 | 57 | ± 2 |
| 32 | 1 | 6210 | 75 | ± 2 |
| Element | IS: 1786 Fe-415 | SAGAR TMT Fe-415 | IS: 1786 Fe-500 | SAGAR TMT Fe-500 |
|---|---|---|---|---|
| Carbon (%) | 0.30 Max | 0.22 Max | 0.30 Max | 0.13 to 0.25 |
| Manganese (Mn %) | --- | --- | --- | 0.50 to 0.70 |
| Sulphur (S %) | 0.060 Max | 0.055 Max | 0.055 Max | 0.050 Max |
| Phosphorus (P %) | 0.060 Max | 0.055 Max | 0.055 Max | 0.055 Max |
| S + P (%) | 0.110 Max | 0.110 Max | 0.105 Max | 0.100 Max |
